Specifications
Specifications |
8t |
|
|
Maximum Operating Radius |
18m
|
|
|
Maximum Ground Lift |
21m |
|
|
Winch Device |
Hook lifting speed |
12m/min (4 ropes) |
|
Specification of steel wire rope |
Φ12mm×80m |
|
|
Telescopic Device |
Boom form |
5m×5-section lifting arm （Support customization） |
|
Boom length/time |
5.5m-21m/54sec（Support customization） |
|
|
Luffing devicedevice |
Boom angle/time |
0-78°/13sec |
|
Gyroscope |
Rotation angle/speed |
0-360°(Continuous)/38sec |
|
Outrigger |
Outrigger movement form |
Manual screw out+oil pressure automatic support (two legs) |
|
Maximum extension amplitude (mm) |
7000 (length) X5070 (rear) X6700 (front) |
|
|
Running Gear |
Walking mode |
Hydraulic motor drive double speed |
|
Walking speed |
0-2.5km/h |
|
|
Gradeability |
25°(36%) |
|
|
Engine |
Manufacturer |
Yunnei （Support customization） |
|
Type/displacement |
490 |
|
|
Start mode |
Electric start |
|
|
Start performance |
-5°C~40°C |
|
|
Fuel/Volume |
Diesel oil/8L |
|
|
Battery capacity |
24V 45AH |
|
|
Emission standard |
National PhaseⅡ |
|
|
Operating System |
Operation type (boom/leg), manual walking |
Manual operation, manual walking(Optional remote control) |
|
Operational Characteristics |
Manual(Optional remote control) |
|
|
Vehicle Size |
6.15 meters length, 1.6 meters width, and 2.25 meters height |
|
|
Dead-weight (T) |
8700kg |
|
|
Track Size |
350 (width) 52.5 (pitch) 104 (section) |
|
|
Optional Device |
Optional torque controller/remote control /hanging basket/Hydraulic fly jib |
|
