· Small working radius, enabling operation in narrow spaces and suitable for trench backfilling.
· Equipped with an international brand HONDA gasoline engine or a high-quality diesel engine, ensuring renowned brand quality, superior performance, and easy starting.
· Adopts a domestic top-brand Tianjin hydraulic travel gear pump or variable pump, providing stepless speed change, forward and reverse travel, and convenient direction switching.
· Machine vibration is controlled by an automatic clutch or an electromagnetic clutch.
· Uses internationally renowned NSK bearings and MITSUBOSHI (Samsung) V-belts, guaranteeing the machine's operational performance.
· The surface is treated with plastic spraying, making it aesthetically pleasing, rust-proof, and corrosion-resistant. This product has obtained CE certification.
|
Category |
Item |
Value |
Category |
Item |
Value |
|
Weight Parameters |
Working Weight |
450 kg |
Compaction Parameters |
Vibration Frequency |
69 Hz |
|
|
Front Weight Distribution |
\ |
|
Nominal Amplitude |
0.48 mm |
|
|
Rear Weight Distribution |
\ |
|
Excitation Force |
11.8 kN |
|
|
Static Linear Load |
39/42 N/cm |
|
Drum Diameter |
Φ426 mm |
|
Mobility Parameters |
Working Speed |
0-2.4 km/h |
|
Compaction Width |
600 mm |
|
|
Theoretical Gradeability |
30° |
Engine |
Model |
CF180FE-4 |
|
|
Minimum Turning Radius |
\ |
|
Type |
Air-cooled Diesel Engine |
|
|
Minimum Ground Clearance |
293 mm |
|
Rated Power |
4.4 kW |
|
|
Wheelbase |
560 mm |
|
Rated Speed |
3600 r/min |
|
Volume |
Hydraulic Oil Tank |
21.5 L |
Water Sprinkler Tank |
23 L |
|
|
|
Fuel Tank |
5.5 L |
|
— |
/ |
Main Dimensions
|
Item |
Value |
Item |
Value |
|
L (Overall Length) |
2285 mm |
H (Overall Height) |
1720 mm |
|
L1 |
1280 mm |
H1 |
1155 mm |
|
L2 |
560 mm |
H2 |
293 mm |
|
W (Overall Width) |
765 mm |
S (Vibration Stroke) |
10 mm |
|
W1 (Compaction Width) |
600 mm |
\ |
\ |
;
