Parameter Item |
Specification |
Parameter Item |
Specification |
|
Maximum Working Radius |
8.5m |
Maximum Ground Lift Height |
10m |
|
Hoisting Device - Hook Lifting Speed |
13m/min |
Steel Wire Rope Specification |
8mm*50m |
|
Telescopic Device - Boom Type |
5-section Boom, Hexagonal Structure |
Telescopic Boom Length |
3m~10.5m |
|
Maximum Boom Extension Length |
7.5m |
Boom Telescoping Time |
Extension: 20 seconds, Retraction: 12 seconds |
|
Luffing Device - Boom Angle/Time |
0~82° (Lifting: 24 seconds, Lowering: 12 seconds) |
- |
- |
|
Slewing Device - Slewing Angle/Speed |
0~360° (Continuous)/60 seconds |
- |
- |
|
Outriggers - Operation Mode |
Manual Rotation + Hydraulic Automatic Support (Two-section Outriggers) |
Maximum Extension Range |
Left/Right (4m), Front/Rear (3.8m) |
|
Travel Device - Travel Mode |
Hydraulic Motor Drive |
Travel Speed |
1.6km/h |
|
Climbing Capacity |
20°(36%) |
Motor Power/Speed |
3kw, 1420r/min |
|
Motor Voltage |
AC380V(50HZ) |
Engine Brand |
Youpu |
|
Engine Start Mode |
Electric Start |
Start Performance |
-5°C~40°C |
|
Engine Fuel/Capacity |
Diesel/11L |
Engine Power/Speed |
12KW, 3000r/min |
|
Battery Capacity |
12V80AH |
Hydraulic Oil Tank Capacity |
40L |
|
Operating System - Operation Type (Boom/Outriggers) |
Manual Operation, Manual Travel |
Operation Characteristics |
Manual Operation |
|
Standard Configurations |
Diesel Engine and Motor (Dual Power) |
- |
- |
|
Overall Vehicle Dimension |
3070mm910mm1725mm |
Total Weight |
2725KG |
